Supported Devices:
WIFI:Windows xp/7/8/8.1/10 Linux/MAC/OSX
Bluetooth:Windows 7/8/8.1/10
Bluetooth instructions:
Bluetooth version: V4.0
Transmission distance: 10 meters
RF power: 10dBm (maximum)
Antenna gain: 2dBi
Transmission speed: 3M/S
Operating current: 100mA-200mA (BT+WIFI) Current changes with operating mode
Support operating system: WIN 7/WIN8/10 operating system
WIFI Description:
Supported standards and protocols: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, CSMA/CA with ACK
Transmission speed: 150Mbps
Frequency range: 2.4 to 2.4835 GHz
Working channel: 1-14
Modulation method: 802.11 g/n: OFDM, 802.11b: CCK (11, 5.5Mbps), QPSK (2Mbps), BPSK (1Mbps)
Transmission rate: 802.11b: 11,5.5,2,1 Mbp 802.11g: 54,48,36,24,18,12,9,6 Mbp 802011n: up to 150Mbps
Receiver sensitivity: 130M: -65dBm@10% PER 108M: -65dBm@10% PER 54M: -65dBm@10% PER 11M: -87dBm@8% PER;
Transmission distance: up to 100 meters in the room and up to 200 meters in the outdoors (depending on the environment)
RF power: 16dBm (maximum)
Antenna gain: 2dBi
Support operating system: Windows 2000/XP/Vista/WIN 7/WIN 8/10/MAC OS operating system
Operating Environment: Operating Temperature: -20°C to 45°C
Storage temperature: -40°C to 70°C
Operating Humidity: 10% to 90% RH Non-condensing
Storage Humidity: 5% to 90% RH Non-condensing
Package:
1 x Wifi+bluetooth Adapter
1 x CD
